Refrigerant Piping Connection
Safety Precautions
WARNING
• All eld piping must be completed by a
licensed technician, and must comply with
all relevant local and national regulations.
• When the air conditioner is installed in a
small room, measures must be taken to
prevent the refrigerant concentration in
the room from exceeding the safety limit,
in the event of refrigerant leakage. If the
refrigerant leaks, and its concentration
exceeds its proper limit, hazards due to
lack of oxygen may result.
• When installing the refrigeration system,
ensure that air, dust, moisture, or foreign
substances do not enter the refrigerant
circuit. Contamination in the system may
cause poor operating capacity, high
pressure in the refrigeration cycle,
explosion, or injury.
• Ventilate the area immediately if there is
refrigerant leakage during the installation.
Leaked refrigerant gas is both toxic and
flammable. Ensure there is no refrigerant
leakage after completing the installation
work.
Notes On Pipe Length and Elevation
Ensure that the length of the refrigerant pipe, the
number of bends, and the drop height between
the indoor and outdoor units meets the
requirements shown in Table 7.1:
Table 7.1: The Maximum Length And Drop
Height, Based on Models. (Unit: m/ft.)
Type of Model Capacity
(Btu/h)
Length of
Piping
Maximum Drop
Height
North America,
Australia and the
EU Models
Inverter Split
Ty p e
<15K 25/82 10/33
15K - <24K 30/100 20/66
24K - <36K 50/164 25/82
36K - 60K 65/213 30/100
Other Split Type
12K 15/49 8/26
18K-24K 25/82 15/49
30K-36K 30/98.4 20/66
42K-60K 50/164 30/100
7
Refrigerant Piping
Connection
Page 18
