Pioneer YN012ALFI19RPD User Manual

Air Conditioner Service Manual
37
-2(-35.6) 63.74 70.48 77.87
52(125.6)
6.309 6.655 7.013 106(222.8) 1.073 1.12 1.168
-1(-33.8) 60.69 67.05 74
53(127.4)
6.08 6.409 6.748 107(224.6) 1.042 1.089 1.136
0(32) 57.81 63.8 70.34
54(129.2)
5.861 6.173 6.495 108(226.4) 1.013 1.058 1.104
1(33.8) 55.08 60.72 66.88
55(131)
5.651 5.947 6.253 109228.2) 0.9833 1.028 1.074
2(35.6) 52.49 57.81 63.61
56(132.8)
5.449 5.73 6.02 110(230) 0.9553 0.9997 1.045
3(37.4) 50.03 55.05 60.52
57(134.6)
5.255 5.522 5.798 111 (231.8) 0.9283 0.9719 1.016
4(39.2) 47.71 52.44 57.59
58(136.4)
5.07 5.323 5.585 112(233.6) 0.9021 0.9451 0.9892
5(41) 45.5 49.97 54.82
59(138.2)
4.891 5.132 5.381 113(235.4) 0.8765 0.9191 0.9626
6(42.8) 43.41 47.62 52.2
60(140）
4.72 4.949 5.101 114(237.2) 0.8524 0.894 0.9367
7(44.6) 41.42 45.4 49.71
61(141.8)
4.556 4.774 4.997 115(239) 0.8087 0.8595 0.9117
8(46.4) 39.53 43.2 42.33
62(143.6)
4.398 4.605 4.817 116(240.8) 0.8059 0.8461 0.8875
9(48.2) 37.74 41.29 45.12
63(145.40
4.247 4.448 4.644 117(242.6) 0.7837 0.8233 0.8641
10(50) 36.04 39.39 43.01
64(147.2)
4.101 4.288 4.479 118(244.4) 0.7623 0.8012 0.8413
11(51.8) 34.42 37.59 41 65(149) 3.961 4.139 4.32 119(246.2) 0.7415 0.7798 0.8193
12(53.6) 32.89 35.87 39.1 66(150.8) 3.827 3.995 4.167 120(248)
13(55.4) 31.43 34.25 37.29 67(152.6) 3.698 3.858 4.021 121(249.8) 0.702 0.7386 0.7773
14(57.2) 30.04 32.71 35.58 68(154.4) 122(251.6) 0.6631 0.7195 0.7572
15(59) 29.72 31.24 33.95 69(156.2) 123(253.4) 0.6649 0.7007 0.7378
16(60.8)
70(158)
3.339 3.476 3.616 124(255.2) 0.6472 0.6824 0.7189
17(62.6) 71(159.8) 3.229 3.359 3.491 125(257) 0.6301 0.6647 0.7006
18(64.4) 25.13 27.26 29.55 72(161.6) 3.122 3.246 3.372 126(258.8) 0.6135 0.6476 0.6829
19(66.2) 24.05 26.07 28.23 73(163.4) 3.02 3.138 3.257 127(260.6) 0.5974 0.6309 0.6657
20(68) 23.02 24.93 26.97 74(165.2) 2.921 3.033 3.146 128(262.4) 0.5818 0.6148 0.649
21(69.8) 22.04 23.84 25.77 75(167) 2.827 2.933 3.04 129(264.2) 0.5667 0.5991 0.6328
22(71.6) 21.1 22.81 24.63 76(168.8) 2.735 2.836 2.938 130(266) 0.5521 0.5839 0.6171
23(73.4) 20.21 21.83 23.55 77(170.6) 2.647 2.743 2.84
R—Resistance
Resistance at 25℃(7 7 )℉ : 20 kΩ
TH3: Outdoor unit discharge pipe sensor
Before measuring resistance, disconnect connectors as shown above.
