107
MAINTENANCE
General Maintenance
NOTE: Do not touch a halogen bulb with bare fingers. Oil from skin
leaves a residue, causing a hot spot that will shorten the life of
the lamp.
Headlight Bulb Removal
1. Pinch the ends of the spring (1)
together and lift until it releases
from the spring retainer.
2. Lift the spring carefully around
the wire harness (2) and flip it
to the outside of the housing.
3. With the wire harness attached
to the bulb (3), withdraw the
bulb from the housing.
4. Grasp the bulb by its metal base
and carefully separate the bulb from the harness.
Headlight Bulb Installation
1. Hold the bulb by its metal base and install it into the wire harness.
2. Insert the bulb into the housing.
3. Carefully flip the spring back into the housing, placing it around the
wire harness.
4. Squeeze the spring together until it's over the spring retainer and
release.
5. Verify headlight aim. See page 106.
1
2
3
