186
Specifications
Outlaw 525 IRS
Max. Weight Capacity 215 lbs./97.5 kg Pilot Jet 45
Dry Weight 395 lbs./179 kg Main Jet 148
Fuel Capacity 3.9 gal./14.8 l Needle Jet OBDVS
Overall Length 71.5 in./182 cm Needle Clip #4
Overall Width 47.5 in./121 cm Slow Air Jet 100
Overall Height 45 in./114 cm Alternator Output 200 w @ 3000 RPM
Wheelbase 51 in./130 cm Compression Ratio 11:1
Ground Clearance 11.5 in./29 cm Starting System Electric
Min. Turning Radius 67 in./170 cm Carburetor Keihin FCR-MX 39mm
Engine Oil Capacity 1.7 qts./1.6 l Ignition System CDI
Coolant Capacity 2.25 qts./2.1 l Ignition Timing 25° +/- 3° @ 3500 RPM in
neutral
Engine ES51KLE Spark Plug Type NGK DCPR8E
Displacement 510 cc Spark Plug Gap 0.6 mm / .024 in.
Bore x Stroke 95 x 72 mm Lubrication System Dry Sump/Internal Reservoir
