SPECIFICATIONS
RANGER® 500
Maximum Weight Capacity (includes
weight of operator, passenger, cargo,
accessories)
1000 lbs. (454 kg)
Dry Weight 1080 lbs. (490 kg)
Test GVW - Rollover Protection System
(ROPS)
2750 lbs. (1247 kg) per OSHA 29 CFR
1928.53
Fuel Capacity 8.8 gal. (33.3 l)
Engine Oil Capacity 2 qts. (1.9 l) (570)
Coolant Capacity 120 oz. (3.5 l)
Overall Length 110 in. (279.4 cm)
Overall Width 58 in. (147.3 cm)
Overall Height 73 in. (185 cm)
Wheelbase 73 in. (185 cm)
Cargo Box Dimensions (Inside) 32x42x11.5 in. (81x107x29 cm)
Ground Clearance 10 in. (25.4 cm)
Min. Turning Radius 150 in. (381 cm)
Towing Capacity 1500 lbs. (680.4 kg)
Hitch Tongue Capacity 150 lbs. (68 kg)
Max. Cargo Box Load 500 lbs. (227 kg)
Engine Single overhead cam, 2 valve 4 stroke
single cylinder.
Displacement 500 cc
Bore x Stroke (mm) 93 mm x 73.6 mm
Alternator Output 560 W @ 3000 RPM
Compression Ratio 10:1
Starting System Electric
Fuel System Electronic Fuel Injection
125
