85
SPECIFICATIONS
RANGER 570 Full Size
Maximum Weight Capacity
(includes weight of operator,
passenger, cargo, accessories)
1500 lbs. (680.4 kg) (4X4)
1300 lbs. (590 kg) (4X4 sold in California)
Dry Weight 1165 lbs. (528 kg)
Test GVW - Rollover Protection
System (ROPS)
2650 lbs. (1202 kg) per OSHA 29 CFR 1928.53
Fuel Capacity 8.8 gal. (33.3 L)
Engine Oil Capacity 2 qts. (1.9 L) with filter
Coolant Capacity 5 qts. (4.75 L)
Overall Length 114 in. (290 cm)
Overall Width 60 in. (152.4 cm)
Overall Height 74 in. (188 cm)
Wheelbase 75 in. (190.5 cm)
Cargo Box Dimensions (Inside) 36.5x54x11.5 in. (93x173x29 cm)
Ground Clearance 10.5 in. (26.7 cm)
Min. Turning Radius 192 in. (487.7 cm)
Towing Capacity 1500 lbs. (680 kg)
Hitch Tongue Capacity 150 lbs. (68 kg)
Max. Cargo Box Load 800 lbs. (363 kg)
600 lbs. (272 kg) (Models sold in California)
Engine Dual overhead cam, 4 valve 4 stroke single cylinder.
Displacement 567 cc
Bore x Stroke (mm) 99mm x 73.6mm
Alternator Output 560 W @ 3000 RPM
Compression Ratio 10:1
Starting System Electric
Fuel System Electronic Fuel Injection
Throttle Body Size 42 mm
Ignition System Digital CDI
Ignition Timing ECU Controlled 32° +/- 2° @ 5000 RPM
Spark Plug NGK MR7F / .031 in. (0.7-0.9 mm)
Lubrication System Wet Sump
Front Suspension McPherson Strut w/9 in. (22.9 cm) of travel
Rear Suspension Dual A-Arm, IRS w/10 in. (25.4 cm) of travel
