96
SPECIFICATIONS
RANGER XP 900
Maximum Weight Capacity
(including operator, passenger,
cargo, non-factory installed
accessories)
1500 lbs. (681 kg) (4X4)
1100 lbs. (499 kg) (4X4 sold in California)
1275 lbs. (578 kg) (4X4 Hunter)
875 lbs. (397 kg) (4X4 Hunter)
Dry Weight 1360 lbs. (617 kg)
1640 lbs. (744 kg) (Hunter)
Test GVW - Rollover Protection
System (ROPS)
3030 lbs. (1374 kg) per OSHA 29 CFR 1928.53
Fuel Capacity 10 gal. (37.8 l)
Engine Oil Capacity 2.5 qts. (2.4 l)
Coolant Capacity 5 qts. (4.75 l)
Towing Capacity 2000 lbs. (907 kg)
Hitch Tongue Capacity 150 lbs. (68 kg)
Max. Cargo Box Load* 1000 lbs. (454 kg)
600 lbs. (272 kg) (Models sold in California)
Overall Length 116 in. (295 cm)
120 in. (305 cm) (Hunter)
Overall Width 60 in. (152.4 cm) (at box)
58 in. (147.3 cm) (at tires)
63.5 in. (161.3 cm) (Hunter, at rock guards/nerf bars)
Overall Height 76 in. (193 cm)
77 in. (195.6 cm) (Hunter)
Wheelbase 81 in. (205.7 cm)
Cargo Box Dimensions (Inside) 36.5 x 54 x 11.5 in. (93 x 137 x 29 cm)
Ground Clearance 12 in. (30.5 cm)
Min. Turning Radius 161 in. (409 cm)
Engine 4-Stroke DOHC Twin Cylinder
Displacement 875 cc
Bore x Stroke 93mm x 64.4mm
Alternator Output 660 W @ 3000 RPM
Compression Ratio 10.5:1
Starting System Electric
Fuel System Electronic fuel injection
Ignition System Electronic
Spark Plug / Gap MR7F / 0.7-0.8 mm
Front Suspension Dual A-arm w/10 in. (25.4 cm) of travel
Rear Suspension Independent w/10 in. (25.4 cm) of travel
Lubrication System Wet Sump
