77
MAINTENANCE
Tires
Wheel Installation
1. Place the
transmission in
neutral.
2. Set the parking
brake.
3. Place the wheel on
the wheel hub with
the valve stem
toward the outside
and the rotation
arrows on the tire
pointing toward
forward rotation.
4. Attach the wheel
nuts and finger tighten.
5. Carefully lower the vehicle to the ground.
6. Torque the wheel nuts to specification.
Improperly installed wheels can adversely affect tire wear and vehicle
handling, which can result in serious injury or death. Always ensure that
all nuts are torqued to specification. Do not service axle nuts that have a
cotter pin installed. Your POLARIS dealer can assist.
Wheel Nut Torque Specifications
Check the wheel nut torques occasionally and when they've been
loosened for service.
Location Nut Torque
Front Wheel 27 ft. lbs. (37 Nm)
Rear Wheel 27 ft. lbs. (37 Nm)
