27
FEATURES AND CONTROLS
Rear Service Panel
The rear service panel is located behind the seats on the frame of the
vehicle. Remove the seats to access the service panel. Remove the ser-
vice panel to access serviceable engine components and clutches.
Radiator Access/Grill Removal
The front grill can be removed to clean debris from the radiator. Push
down on the two tabs and pivot the grill outward to remove it.
Seats
Before operating the vehicle, always push down on all seat backs to
ensure the latches are secure.
Seat Adjustments
On seats equipped with an adjustment lever, pull upward on the release
lever located under the front edge of the seat. Slide the seat forward or
rearward to the desired position. Release the lever. The seat will lock
into the new position.
For other seat styles, loosen (do not remove) the four screws located on
the seat bottom. Slide the seat forward or rearward to the desired posi-
tion. Tighten the screws to 4 ft. lbs. (5.4 Nm). Do not overtighten.
Seat Removal
1. Pull up on the seat latch
lever located under the rear
edge of the seat.
2. Tilt the seat forward.
3. Lift the seat upward to
remove it from the vehicle.
4. Reverse this procedure to
reinstall the seat. Make
sure the seat tabs at the
front edge of the seat slide
under the seat retainer bar.
5. Press down firmly at the
rear of the seat to engage
the rear latch.
Front Seat
Retainer
Seat
Latch
