9. Insert the clutch spreader tool into the driven clutch.
10. Turn the tool clockwise to open the sheaves on the driven clutch.
11. Walk the belt out of the driven and drive clutch. Remove the belt.
12. Remove ALL debris wrapped in and around the PVT system.
13. Remove ALL debris from the entire clutch air duct passage.
14. Check for signs of damage to seals on the transmission and engine. If any
seals appear to be damaged, your vehicle requires prompt service. Your
POLARIS dealer can assist.
15. Once finished, return the clutch spreader tool to the clutch housing and
reattach the clutch cover.
16. Tighten the five quick release fasteners located on the lower part of the
clutch cover, then reinstall the 5 clutch cover bolts securing the top of the
clutch cover.
TORQUE
Clutch Cover Bolts:5 Nm (37 ft-lbs)
17. Reattach the PVT inlet duct to the outer clutch cover (and fasten with the
clamp).
18. Reinstall and secure the close off panel.
19. Reinstall the seats. Ensure the seats latch securely.
113
MAINTENANCE
