Polycom CX700 Specifications

Size
252.7 x 268.6 x 91.3 mm (9.95 x 10.57 x 3.59 in) •
when device is not tilted
193.2 x 268.6 x 192.1 mm (7.61 x 10.57 x 7.56 •
in) when device is tilted up
Weight
Unit: 2.1 kg (4.6 lbs)•
Handset: 200 g (7 oz)•
Shipping Weight: 2 kgs (4.4 lbs..)•
Power
Power Over Ethernet IEEE 802.3af Class 2 (PoE)•
13-Watt maximum consumption Universal AC/DC •
switching power adapter
LCD Display
5.7” amorphous-TFT Active-Matrix Transmissive •
color LCD
Resistive touch-panel•
Backlight unit•
320x240 resolution, 18 bit per pixel•
Device Controls and Keypad
3x4 telephony dialpad (0-9, A-Z, *, #)•
Headset on/off button•
Speakerphone on/off button•
Mute on/off button•
Volume control•
Help button•
Touch wheel with center select button•
Biometrics fingerprint reader•
Device to Network Connectivity
Ethernet switch 2-port Ethernet switch 10/100 •
Base-T with RJ45 connector ports and activity
LEDs:
IEEE 802.3af Class 2 PoE Ethernet 10/100 •
Base-T
IEEE 802.3 Ethernet 10/100 Base-T•
USB Ports
Type-A and Type-B supported (Type A connector is •
for use with certified UC devices only)
USB 1.1/USB2.0 compatible•
Full speed (12 MBPS) port•
LED Indicators
Off hook indicator•
Voice messaging indicator•
Call forwarding indicator•
Multi-color presence LED indicator•
Audio
Frequency response: 30 – 20kHz•
Signal-to-noise ratio: 78 dB (@ 1kHz)•
Dynamic range: >80 dB (@ 1kHz)•
Total Harmonic Distortion + Noise: <0.08% •
(@ 1 kHZ)
Auxiliary Audio Output
RJ9 headset jack with built-in amplifier•
Audio Enhancements
Automatic Gain Control•
Dynamic Noise Reduction•
Acoustic Echo Cancellation•
Environmental Requirements
Temperature: -10°C to 40°C (14°F to 104°F)•
Relative Humidity: 80% max (non- condensing)•
Altitude: -304.8 meter to 3962.4 meter (-1000 •
feet to13,000 feet)
Light Exposure: Fluorescent overhead lighting and •
window-filtered daylight (typical offices)
Regulatory Compliance – Approvals Gained
•ElectricalSafety•
UL60950-1 (USA / Canada) -
IEC / EN60950-1 (EU) -
GOST -
MIC -
CQC -
EMC – General•
CISPR22 -
EMC – USA (Class B)•
FCC Part 15 -
EMC - Canada (Class B)•
ICES00.3: 1998 -
EMC – EU (Class B)•
EN 55022 -
EN 55024 -
EMC – ROW (Class B)•
C-Tick (Australia) -
VCCI (Japan) -
GOST (Russia) -
MIC (Korea) -
CQC (China) -
Warranty
12 Months•
Polycom Communicator Ships With:
CX200 CX200 Desktop Phone base•
Handset•
6 ft. handset curly cord•
Captive USB cable•
Quickstart Guide•
Warranty card•
Polycom
®
CX700 IP Phone Specifications
www.polycom.com
Polycom Headquarters Polycom EMEA Polycom Asia Pacific
4750 Willow Road 270 Bath Road 8 Shenton Way
Pleasanton, CA 94588 Slough #11-01 Temasek Tower
1.800.POLYCOM or Berkshire SL1 4DX Singapore 068811
+1.925.924.6000 +44 (0)1753 723000 +65.6389.9200
Part No. 3726-17861-001 Rev 01/23/09
©2009 Polycom, Inc. All rights reserved.
Polycom and the Polycom logo design are registered trademarks of Polycom, Inc. in the U.S. and various countries.
All other trademarks are the property of their respective owners. Information in this document is subject to change without notice.

Polycom CX700 Specifications

Power

power over Ethernet	IEEE 802.3af Class 2
maximum power consumption	13 Watts

LCD Display

display size	5.7 inches
display type	amorphous-TFT Active-Matrix Transmissive
display resolution	320x240

Audio

frequency response	30 – 20kHz
signal-to-noise ratio	78 dB (@ 1kHz)
dynamic range	>80 dB (@ 1kHz)
total harmonic distortion + noise	<0.08% (@ 1 kHz)

Operating Environment

operating temperature range	-10°C to 40°C
relative humidity	80% max (non-condensing)
operating altitude range	-304.8 meter to 3962.4 meter

Weight and Dimensions

dimensions when not tilted	252.7 x 268.6 x 91.3 mm
dimensions when tilted up	193.2 x 268.6 x 192.1 mm
unit weight	2.1 kg
handset weight	200 g
shipping weight	2 kgs
