Figure 11
Figure 12
2.1.1 Tools in Installing
Please make sure all tools and cables are ready and conform to the industrial safety standard before installation.
Please refer to Figure 11.
The installation procedure of PW320/PW330/PW330L may be changed due to various accessories and quantities
installed. The basic wiring diagram is shown in Figure 12.
No wiring cables for accessories are supplied with KIT PW320/PW330/PW330L.
2.1.2 Motors, Components and Its Installation in Illustration
PW320/PW330/PW330L is required to connect two cores wires, which requires very low voltage that no
professionally trained personnel is required in installation; however, the users are advised to read the installation
manual carefully before going for it. After getting to know all accessories and their positions, suggest starting from
cable conduit arrangement to prevent the cables from being broken or damaged
2.2 Power Connection
1. The installation of power supply cable to the motor should be carried out by a qualified professional electrician.
2. The power supply cable of the motor should be equipped with short circuit protection and leakage protection.
Please make sure to shut off the power before going installation or maintenance.
2.2.1 Notes for Power Connection
