Powtran PR5200 022G3 User Manual

13
第
十
章
Section V Control panel and operation
★PR5200(C)series soft starter has five kinds working
state:ready,running,error,start and stop. Ready、running、error has corresponding state
light.Startup indicates××××，softstop indicates —××× ,and ×××××indicates motor
current.
5-1 Keyboard operational approach
JP3E5200 keyboard diagram
Ampere
Percentage
Second
Error light
Bypass
light
Colon
blank
Ready light
Three digitals
Two position
function code
Parameter Alternation
Key (acc/reduction key)
parameter
setting/shift
key
Rapid select/confirm
parameter setting
Running Key
Stop/reset key
JP3E5200D keyboard diagram
Ampere
Percentage
Second
Error light
Bypass
light
Colon
blank
Ready light
Three digitals
Two position
function code
Parameter Alternation
Key (acc/reduction key)
parameter
setting/shift
key
Rapid select/confirm
parameter setting
Running Key
Stop/reset key
