ASSEMBLY
Place all parts of the exercise cycle in a cleared area and remove the packing materials. Do not dispose of the
packing materials until assembly is completed.
Assembly requires the included tools and your own adjustable wrench .
Refer to the drawings below to identify the small parts needed for assembly. The number in parenthesis below
each drawing is the key number of the part, from the PART LIST on page 22. The number following the key
number is the quantity needed for assembly. Note: Some small parts may have been pre-assembled. If a
part is not found in the parts bag, check to see if it has been pre-assembled.
M6 Washer
(25)–6
M8 Split
Washer (70)–4
M8 Flat
Washer (18)–4
M8 Nylon
Locknut (56)–8
M10 Nylon
Locknut (63)–4
M4 x 16mm
Screw (21)–4
M4 x 21mm
Screw (81)–2
M6 x 16mm
Screw (62)–2
M8 x 19mm Button
Bolt (43)–4
M8 x 25mm Button
Screw (27)–4
M8 x 39mm Button
Bolt (47)–4
1/4” x 16mm Hex
Screw (29)–4
1/4” x 38mm Hex
Screw (78)–4
M10 x 91mm Carriage Bolt (35)–2
M10 x 105mm Carriage Bolt (36)–2
