INSTALLATION INSTRUCTIONS
Name of components
4
145*210mm 10-GBR英语
Ice box
Honeycomb Filter
Water Tank
Water Tank Plug
Circlip
Considerate Hint:
1. Insert an ice box into the water tank before installing the honeycomb
filter.
2. When humidifying, water level in the Water Tank must remain under
MAX indication; replenish water if level gets lower than MIN indication.
3. When filling the water tank, make sure that the stopper
and spring are properly positioned.
Foot-wheel
Foot-Wheel Installation Removing the honeycomb filter
Honeycomb
Filter Frame
Honeycomb Filter
Gently pull out the honeycomb
filter from the stand to remove it.
