Tool Specifications GB
Mixer MXP 800 E MXP 1000 EQ
Voltage 230 – 240 V 230 – 240 V
Frequency 50/60 Hz 50/60 Hz
Power input 780 W 950 W
No-load speed: 340 – 900 rpm 260 – 700 rpm
Electronic speed pre-selection • •
Mains cable module (Plug it) – •
Tool holder M 14 x 2 M 14 x 2
Stirrer – ∅ (max.) 120 mm 140 mm
Clamping collar dia. 43 mm 57 mm
Weight 2.5 kg 4.8 kg
Protection class II /
II /
Operating controls
1 Auxiliary handle
2 On/Off switch with speed control
3 Lock-on button
4 Thumbwheel for speed pre-selection
5 Venting slots
6 Tool holder
7 Wrench flats
8 Open-end wrench
9 Stirrer
(not included in the standard delivery)
10 Socket (MXP 1000 EQ)
11 Sleeve (MXP 1000 EQ)
12 Mains cable module (MXP 1000 EQ)
Not all of the accessories illustrated or described
are included as standard delivery.
Intended Use
The machine is intended for stirring powder-type
building materials such as mortar, plaster,
cement, and solvent-free paints, varnish and
similar substances.
The user alone is responsible for any liabilities
caused by usage other than intended.
Symbols used in the manual
and on the machine
Not to be included in municipal refuse.
Double insulation.
This symbol is used to mark safety
instructions that must be observed to
prevent damage to persons.
Notes on Safety
This machine can only be operated
safely when the operating and
safety instructions are completely
read and strictly observed.
G For further notes on safety refer to the en-
closed sheet.
G Always check the machine, cable and plug
before using. Have damages repaired only by
a qualified professional.
G The machine should not be operated in damp,
wet locations; nor in the open during a rain,
fog and snow, or in environment with a risk of
explosion.
G Connect machines that are used in the open
via a residual current device (RCD) with an
actuating current of 30 mA maximum. Use
only extension cables that are approved for
outdoor use.
