9
Technical data
Operating controls & Description
Intended use
GB
1. Main handle of the planer
2. Mains switch
3. Lock-off button
4. Overload indicator (LED diode)
5. Front handle, swiveling (for planing depth
adjustment)
6. Planing depth scale
7. Locking lever of planing depth adjustment
8. Front shoe, adjustable
9. Fixed shoe
10. Pivoted guide roller
11. Air inlet openings
12. Chip discharge opening
13. Machine housing cover
14. „V“ groove for chamfering
15. Cutting head with blades
16. Reversible blade
17. Blade backing plate
18. Blade clamping rail
19. Hole for insertion of the locking pin for blade
replacement, preventing rotation of the
cutting head
20. Blade fixing screws
21. Open-ended wrench (No. 8/13)
22. Cutting head guard
23. Driving belt guard
24. Carbon brush cap
25. Hexagon-head screw of the machine
housing cover
The accessories shown or described in this
Operating Manual may not be included as a part
of delivery.
The carpentry planer is universally applicable for
planing and smoothing of visible surfaces on
rafters, e.g. projecting rafters, rafter ends and
purlins; it may be also utilized for planing
structural timber and lattice work, as well as for
other carpentry works or woodworking in
general.
The user is solely liable for damage and
accidents caused by improper use of the
product.
For safe work with this electric tool and
prevention of injury, it is imperative to follow all
generally accepted safety principles and
regulations for prevention of accidents, and read
the enclosed “Safety instructions” thoroughly.
The manufacturer disclaims liability for damages
caused by unauthorized modifications or using
other than the supplied or specified accessories
with the electric tool.
Type reference PLP 205 E PLP 245 E
Voltage 230 V 230 V
Frequency 50 - 60 Hz 50 - 60 Hz
Rated input 2 000 W 2 300 W
Power output 1 380 W 1 500 W
Speed: no-load 13 500 min 13 000 min
rated load 9 000 min 10 500 min
Planing depth 0-3mm 0-3mm
Planing width 205 mm 245 mm
Weight of the electric tool 13 kg 14 kg
Safety Class II / II /
-1 -1
-1 -1
~~
