31
Air Compressor
PARTS LISTING
PARTS NO. DESCRIPTION QTY.
PCE6280-01 BO LT M8X103 4
PCE6280-02 CYLINDER COVER 1
PCE6280-03 CYLINDER COVER GASKET 1
PCE6280-04 VALVE PLATE 1
PCE6280-05 VALVE CLACK 1
PCE6280-06 VALVE CLACK GASKET 1
PCE6280-07 CYLINDER 1
PCE6280-08 CYLINDER GASKET 1
PCE6280-09 PISTON RING 3
PCE6280-10 PISTON 1
PCE6280-11 CIRCLIP 2
PCE6280-12 CONNCTING ROD 1
PCE6280-13 CRANK CASE 1
PCE6280-14 CRANK 1
PCE6280-15 HEX BOLT M8X22(LEFT) 1
PCE6280-16 RUBBER GASKET 1
PCE6280-17 BREATH PIPE 1
PCE6280-18 SEALED RING Φ13X2.5 2
PCE6280-19 CRANK CASE COVER 1
PCE6280-20 BO LT M6X10 6
PCE6280-21 OIL LEVELER GASKET 1
PCE6280-22 OIL LEVELER 1
PCE6280-23 ONLY-WAY VALVE 1
PCE6280-24 HAND 1
PCE6280-25 TIGHT SETTLE THE BOLT 2
PCE6280-26 WHEEL BOLT M10 2
PCE6280-27 WHEEL 2
PCE6280-28 SPRING WASHER 10 2
PCE6280-29 WASHER 10 2
PCE6280-30 LOCK NUT M10 2
PCE6280-31 TANK 1
PCE6280-32 DRAIN VALVE 1
PCE6280-33 BOLT M8X25 1
PCE6280-34 WASHER FOOT 1
32
Owner’s Manual
PARTS LISTING
PARTS NO. DESCRIPTION QTY.
PCE6280-35 WASHER 8 1
PCE6280-36 NUT M8 1
PCE6280-37 PLUG LINE 1
PCE6280-38 RELEASE PIPE 1
PCE6280-39 THE CONJUNCTION IS HEXANGULAR 1
PCE6280-40 NUT RP 1/2 1
PCE6280-41 REGULATOR VALVE 1
PCE6280-42 SAFETY VALVE 1
PCE6280-43 LOCK NUT M8 4
2
2
1
PCE6280-44 QUICK COUPLERS
PCE6280-45 PRESSURE GAUGE
PCE6280-46 PRESSURE SWITCH
PCE6280-47 LOCK BOLT M8X30 4
PCE6280-48 DISCHARGE PIPE 1
PCE6280-49 STATOR 1
PCE6280-50 BREARING 6203 1
PCE6280-51 CONUGATED WASHER 1
PCE6280-52 MOTOR COVER 1
PCE6280-53 BO LT M5X105 4
PCE6280-54 FAN 1
PCE6280-55 CRICLIP 1
PCE6280-56 BO LT ST3.9X19 2
PCE6280-57 BOLT M5X8 2
PCE6280-58 ROTOR 1
PCE6280-59 BREARING 6204 1
PCE6280-60 SEALING RING 1
PCE6280-61 CAPACITANCE 1
PCE6280-62 WASHER 8 1
PCE6280-63 NUT M8 2
PCE6280-64 PISTON PIN 1
PCE6280-65 FAN COVER 1
PCE6280-66 COLUMN Φ32
PCE6280-67 AIR FILTER 1
PCE6280-68 CURVED HEAD 1
