PG1202S MANUAL
Control System Assy
H
No.
Parts No.
Description
1
PG1202S-H-01
FLAT SCREW (M6× 40)
2
PG1202S-H-02
CONTROL ADJUSTING SPRING
3
PG1202S-H-03
SPEED GOVERNING GASKET
4
PG1202S-H-04
SPEED GOVERNING SPRING
5
PG1202S-H-05
FLANGE NUT (M6)
6
PG1202S-H-06
SHIFTET
7
PG1202S-H-07
GOVERNOR ARM
8
PG1202S-H-08
BOLT (M6× 20)
9
PG1202S-H-09
THROTTLE RETURN SPRING
10
PG1202S-H-10
GOVERNOR ROD
11
PG1202S-H-11
SPEED REGULATION FORK
12
PG1202S-H-12
WASHER (Ф3)
13
PG1202S-H-13
SPRING WASHER (Ф3)
14
PG1202S-H-14
FLAT SCREW (M3× 8)
15
PG1202S-H-15
SLIP RING
16
PG1202S-H-16
FLANGE BOLT (M6× 12)
17
PG1202S-H-17
STAND
