9
ASSEMBLY
Unpacking
1. Place box on a level surface.
2. Remove all items from box except the generator. Make sure all items listed on the packing list are included and not
damaged.
3. Cut down the sides of the box being careful to avoid hitting the generator.
4. Leave generator on box to install wheel assembly.
Packing List
Check all loose parts to the following list. Contact your dealer if any loose parts are not included.
Description Qty
Generator
1
Operator’s manual
1
Product registration card
1
Toolkit
Spark Plug Wrench
1
1
Description Qty
Supporting Leg
Screw
Nut
2
2
2
Funnel
+ +
+
+ ++ +
( )
++ +
+ + +
Wheel Assembly
Foot Assembly
Description Qty
Handle
Screw
Nut
1
4
4
Wheels
2
Hair pin
2
Axles
2
Washer
2
Handle Bracket 1
1Handle Clip
Handle Assembly
+
+
+
To Next Page
