OPERATION
approved by Microsoft.
USB MP3 player is not a standard
which means different brand name or
different models have their own
standard. So our product cannot
support every MP3 player.
When connecting an MP3 player and
there has normal battery in the player
(non rechargeable battery), you should
remove the battery from the MP3
player then connect it to the USB
interface. Otherwise, it may cause
battery burst.
When in USB play mode, be sure not to
remove the USB driver from the USB
interface.
SD OPERATION
There is a SD interface (25) on the front
panel of the unit.
When you insert a SD card in the SD
interface, the unit will search the MP3/WMA
files in the card and start to play MP3/WMA
files automatically. The
operation is the same with the MP3
operation described above. If in other
mode.
you can also press MOD button to select
SD mode.
When there are important files in the SD
card, do not connect it to the main unit to
play.
SUPPORTED MP3/WMA DECODING
MODES
The main unit supports MP3/WMA
(Windows Media Audio) decoding modes
as below.
The USB solution can support:
1. Folder: 500 max.
2. File: 999 max.
3. Depth of folder: 8 layers
4. Size: 2 GB
CAUTION
When there are important files in the USB
device, do not connect it to the main unit to
play. And don‟t play the CD-R/RW disc that
has important files in it. Because any wrong
operation may cause files loss. And our
company assumes no responsibility for this.
DISC NOTES
A. Notes on discs:
Attempting to use non-standard shape
discs (e.g. square, start, heart) may
1. damage the unit. Be sure to use round
shape CD discs only for this unit.
2. Do not stick paper or tape, etc, onto the
label side or the recording side of any
discs, as it may cause a malfunction.
3. Dirt, dust, scratches and warping discs
will cause mis-operation.
B. Notes on CD-Rs (recordable
CDs)/CD-RWs (rewritable CDs):
1. Be sure to use discs with following
marks only for the unit to play:
To Next Page
