Pylontech Force-L2 Product Manual

19PIFP0301
This manual introduces Force-L2 from Pylontech. Force-L2 is a 48Vdc Lithium-Ion Phosphate
Battery storage system. Please read this manual before you install the battery and follow the
instruction carefully during the installation process. Any confusion, please contact Pylontech
immediately for advice and clarification.
CONTENT
1. SAFETY PRECAUTIONS ..................................................................................................................... 1
1.1 Before Connecting .................................................................................................................... 1
1.2 In Using ..................................................................................................................................... 2
2. INTRODUCTION ...................................................................................................................................... 3
2.1 features: .................................................................................................................................... 3
2.2 Specifications ............................................................................................................................ 4
2.2.1 The parameter of system ....................................................................................................... 4
2.2.2 Battery Module (FL4874M) .................................................................................................... 6
2.2.3 Control Module FC0048M-100 (internal power supply) ........................................................ 7
Definition of RJ45 Port Pin ........................................................................................................... 11
3. EMERGENCY SITUATIONS ............................................................................................................... 12

Pylontech Force-L2 Specifications

General

Battery Type	Lithium Iron Phosphate (LiFePO4)
Nominal Voltage	51.2 V
Capacity per Module	3.55 kWh
Usable Energy	3.2 kWh
Operating Temperature	-10°C to 50°C
Communication Interface	CAN, RS485
Warranty	10 years
Peak Discharge Current (3 sec)	100 A
Protection Degree	IP20
Cycle Life	6000 cycles at 80% DoD
