1. Introduction
LV-Hub is the CAN/RS485 communication hub for multiple 48V battery groups in parallel connection.
Fit Description: US2000 / US3000 / Phantom-SA / US1800.
2. LV-Hub-A
No. Item Parameter
1 Operating voltage range 48 Vdc
2 Communication interface CAN/RS485
3 System Consumption 2W
4 Size 442*190*44mm
5 Protection degree IP20
6 Weight 3.0kg
7 Operation Life 15 years
8 Working temperature -20~60℃
9 Storage temperature -40~80℃
10 CAN (Max 25 groups) Baud rate: 500K; terminal resistance: 0/120Ω
11 RS485 (Max 5 groups) Baud rate:9600/115200

Pylontech US3000C Specifications

General

Battery Type	Lithium Iron Phosphate (LiFePO4)
Nominal Voltage	48V
Capacity	74Ah
Discharge Current (Recommended)	37A
Discharge Current (Maximum)	74A
Communication	CAN, RS485
Cycle Life	6000 Cycles @ 25°C
Operating Temperature	-10°C to 50°C
Scalability	Up to 16 units in parallel
Certification	CE, UN38.3
