II COMPONENTS
Pic. 1
III INSTALLATION AND OPERATION
Unpacking and cleaning the wine cooler
Remove the exterior and interior packing materials.
Let the appliance stand upright for approximately 12 hours before con-
necting it to the power source, which helps to reduce the possibility of a coo-
ling-system malfunction from handling during transportation.
Use a soft cloth to clean the interior surface with lukewarm water.
Install the door handle provided with the appliance by following these steps:
pic. 2
1. Remove the gasket at the inner side of the door to expose the two screw
holes.
2. Install the handle tightly with the screws and washers provided
3. Tidy and restore the gasket
Installation
Pic. 3
BWK 1622
1. After installed wine cellar into cooler, please adjust limited block (a) close to
cooler (e)
2. Please fix the 3 pcs screws through the limited block (a) screw hold into coo-
ler (e), pic. 4
Reverse the door swing (Only BWK 1607, BWK 1618, and BWK 1651)
Remarks:
The instruction is based on a unit with right door hinge installed already.
To reverse the door from right hinge to left hinge, you need to get ready 2
new spare parts: an upper left hinge, and a bottom left hinge. Both these
left hinges plus accompanying screws are included inside the package with
the wine cooler. All removed parts must be saved to do the door reinstalla-
tion, except those remarked with “Disused”.
1 Open the door, and loosen the 2 screws 1 and 2.(pic. 5-1).
2 Carefully remove the door from the upper right hinge 4 and prevent it from
scratching. Take out the support rod 3 from the door hinge hole. (pic. 5-2).
3 Pull out the 6 decorating plastic plugs covering the reserved hinge screw
holes at the front left corner of the cabinet and move them to the right side
4 Unscrew the upper right hinge 4 (Disused) and bottom left hinge 6
(Disused) from the cabinet. (pic. 5-3). Install the upper left hinge 7 and
bottom left hinge 8 to the left side of the cabinet. Make sure that the
screws are tightened. (pic. 5-4).
5 Put the door upside down and install it to the left hinges by following the
opposite steps of taking down of the door as described above.
6 Cover the hinge screw holes on the right side with the 6 decorating plastic
bolts
4
76

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Qlima BWK 1607 and is the answer not in the manual?

Qlima BWK 1607 Specifications

General IconGeneral
Inner colorBlack
Housing colorSilver
Number of doors1 door(s)
Reversible doorsYes
Shelves materialWood
Number of shelves7 shelves
Appliance placementBuilt-in
Noise level44 dB
Product typeCompressor wine cooler
Climate classN
Bottles capacity7 bottle(s)
Total net capacity20 L
Refrigerating mediumR600a
Temperature range (zone 1)5 - 18 °C
Number of temperature zones1
Current0.5 A
Connected load70 W
AC input voltage220 -240 V
AC input frequency50 Hz
Energy efficiency scaleA+++ to G
Annual energy consumption135 kWh
Lamp typeLED
Door open alarmNo
Package depth510 mm
Package width175 mm
Package height890 mm
Package weight21000 g
Weight and Dimensions IconWeight and Dimensions
Depth471 mm
Width145 mm
Height865 mm
Weight19000 g
