Qlima P522 User Manual

4
57
Programming start up
• Turn on the appliance, choose the mode you want, for example cool, 24°C, high
fan speed.
Turn off the appliance.
• Press the
button, the screen will display 1-24 hours, and the
symbol and
symbol and symbol are flash together.(fig 3)
• Press several times until the corresponding time is displayed.Wait about 5
seconds, the timer will be active, then only the
symbol is displayed on screen.
(fig 4)
• Press again the
button or the
button, the timer will be canceled, and the
symbol will disappear from screen.
Programming shut down
• When the appliance is running, press the
button, the screen will display hours,
and several symbols are flash together. (fig 5)
• Press several times until the corresponding time is displayed. Wait about 5
seconds, the timer will be active. then only the
symbol is displayed on screen.
(fig 6)
• Press again the
button or the
button, the timer will be canceled, and the
symbol will disappear from screen.
Fig. 5 Fig. 6 Fig. 7
The remote will come with a battery already installed. To use the
remote for the first time, remove the transparent insulating strip
from the battery housing by gently pulling it out.
Replacing the Battery
To replace the battery, follow the steps below:
1
Press down the pin and remove the battery cover.
2
Replace the battery and slide the battery cover back into the remote;
Pin (accessories
not included
Zoom in
Cover
hole
Insert the pin to the cover
hole and then press
Push the cover out at
the same time
Battery cover
Battery (type:
CR2025)
Fig. 3
Fig. 4
Insulating
strip
Remove

Qlima P522 Specifications

General

Type	Monobloc mobile air conditioner
Timer	Yes
Noise level	65 dB
Number of speeds	3
Airflow (high speed)	330 m³/h
Refrigerating medium	R410A
Cooling capacity (max)	- BTU/h
Dehumidifying capacity	0.7 l/h
Air conditioner functions	Cooling, Dehumidifying
Cooling temperature range	18 - 32 °C
Refrigerating medium weight	410 g
Suitable for room volume up to	75 m³
Cooling capacity in watts (max)	2200 W
Heating capacity in watts (max)	- W
Cooling energy efficiency (EER, W/W)	2.6
Heating energy efficiency (COP, W/W)	-
Current	3.7 A
AC input voltage	220-240 V
AC input frequency	50 Hz
Energy efficiency class (cooling)	A
Energy efficiency class (heating)	No
Hourly energy consumption (cooling)	0.8 kWh
Hourly energy consumption (heating)	- kWh
Product color	White

Weight and Dimensions

Depth	690 mm
Width	415 mm
Height	315 mm
Weight	24000 g
Package depth	844 mm
Package width	462 mm
Package height	357 mm
Package weight	28000 g
