IMPORTANT
COMPONENTS
1. READ THE DIRECTIONS FOR USE FIRST.
4
50
2. IN CASE OF ANY DOUBT, CONTACT YOUR DEALER.
Outlet blade
Control panel
Cover
Handle
Side plate
Front plate
Roller
Back air inlet grille
Water inlet and knob
Water outlet and knob
Back plate
A
B
C
4
E
F
G
H
9
J
K
ACCESSORIES
A
B
One inlet pipe and
one outlet pine
Versatile water pipe
joint
