A number of other software packages are now also capable of decoding WSPR transmissions.
NOTE: the GPS interface is connected in parallel in the circuit, with the paddle. Therefore, you
should NOT have the GPS connected, while operating the radio as an ordinary CW transceiver. If
you do, the GPS serial data and 1pps will key the transmitter! Disconnect the GPS before using
the radio as a CW transceiver.
The following sections describe the configuration parameters in the Beacon menu.
6.1 Mode
WSPR
This parameter determines the transmission mode during beacon operation. There are four
possible beacon modes:
OFF: The beacon mode is off, the transceiver is in ordinary manual operating mode
CW: the kit simply sends stored message 1 repeatedly, according to the configured Keyer speed,
and with message start timing determined by the Frame and Start parameters (see next sections).
QCX operang manual, rmware 1.07, manual edit 0.03 26
