Assembly
Preparing to assemble the hand push mower
Step 1 - Attaching the handle
Keep all packaging until the hand push mower is fully assembled and has been operated
successfully. Always recycle the packaging in accordance with local recycling schemes.
1. Secure the upper handle (A) to the mid handles(B) with two carriage bolts and two wing knobs.
2. Secure the handle assembled in step 1 to the lower handle(C) with four carriage bolts and four
wing knobs.
ylbmessA
Step 1 - Attaching the handle
Step 2 - Attaching the grass collection box
3. Position the complete handle assembly over the studs on the rear of mower frame.
WARNING!
- The grass collection box must be fitted before using the mower.
A
B
C
IMPORTANT! Before assembling the hand push mower, check all the parts indicated in the
manual are in the box. Inspect all the parts for signs of damage. Do not assemble the hand push
mower if you observe any damaged components.
