L80&L80-R&L86&LC86L EVB User Guide
L80&L80-R&L86&LC86L_EVB_User_Guide 8 / 30
2 General Overview
2.1. Top View
The following figure illustrates the top view of the EVB.
Figure 1: Top View of the EVB
Table 1: Available Interfaces
SN.
Reference Number
Description
A
J403
Antenna connector
1)
B
D303, D304, D305, D306,
D307
Indication LEDs
2)
(see Chapter 3.4 for details)
