Smart Module Series
SC206E_Series_Hardware_Design 68 / 115
4 Wi-Fi/Bluetooth
The module provides a shared antenna interface ANT_WIFI/BT for Wi-Fi and Bluetooth functions. The
interface impedance should be controlled to 50 Ω. You can connect external antennas such as PCB
antenna, sucker antenna, and ceramic antenna to the module via the interface to achieve Wi-Fi and
Bluetooth functions. Bluetooth and WLAN (both 5G and 2.4 G) are operating in TDD under coex mode.
4.1. Wi-Fi
The module supports 2.4 GHz and 5 GHz dual-band WLAN based on IEEE 802.11a/b/g/n/ac standard
protocols. The maximum data rate is up to 150 Mbps in 2.4 GHz bands, and 433 Mbps in 5 GHz bands.
The features are as below:
⚫ Supports Wake-on-WLAN (WoWLAN)
⚫ Supports ad hoc mode
⚫ Supports WAPI SMS4 hardware encryption
⚫ Supports AP and STA mode
⚫ Supports Wi-Fi Direct
⚫ Supports MCS 0–7 for HT20 and HT40
⚫ Supports MCS 0–8 for VHT20
⚫ Supports MCS 0–9 for VHT40 and VHT80
4.1.1. Wi-Fi Performance
The following table lists the Wi-Fi transmitting and receiving performance of the module.
Table 28: Wi-Fi Transmitting Performance
