Quick 969D+ User Manual

11
4) Screw on
⑤
Nipple and Install
①
Soldering tip.
5) Put
②
Tip enclosure and
③
Nut on
⑤
Nipple and screw them tightly.
6) After replacing the heater, the following measurements are recommended:
7)After the replacement of the heater, it is recommended to calibrate temperature, refer
to 11temperature calibration
14. Fault Descriptions
No.
Error
Fault descriptions
1
S-E
The sensor is error
If the sensor or other parts of the sensor circuit fails, the "S-E"
mark is displayed and the current to the soldering iron is cut off.
2
H-E
The heater is error
If the soldering station cannot deliver power to the soldering iron
heater, the window displays "H-E", indicating that the heater is
damaged.

Quick 969D+ Specifications

General

Brand	Quick
Model	969D+
Category	Soldering Gun
Language	English
