DK Series
EN
QUICK DKSeries INSTALLATION AND USER’S MANUAL - REV005A
14
3
200...690 Vac
M
3
～
5 - Wiring diagram
MULTI-PURPOSE
PUSH-BUTTON PANEL
FOOT-OPERATED SWITCHES
5.4 - Example of connection of 400V DK 4000W - 5500W with INVERTER
WINDLASS
generic image
THREE-PHASE POWER
SUPPLY
FUSE
INVERTER
