DYLAN DH 1500/1700/2000W - REV001A
21
MAINTENANCE
WARNING:
make sure the electrical power to the motor is
switched off when working manually on the windlass. Care-
fully remove the chain or rope from the gypsy or the rope
from the drum.
Quick
®
windlasses are manufactured with materials resistant to
marine environments. In any case, any salt deposits on the outside
must be removed periodically to avoid corrosion and damage to the
equipment.
The parts where salt may have built up should be washed thor-
oughly with fresh water.
Once a year, the drum and the gypsy are to be taken apart as follows:
DRUM VERSION
Use the handle (1) to loosen the bush (7); pull off the drum (6) and
the top clutch cone (8); loosen the fixing screws (11) of the rope/
chain stripper (12) and remove it. Pull off the gypsy (9).
NO-DRUM VERSION
Use the handle (1) to loosen the bush (2) and the screws (5); to
remove the gypsy cover (4); and the top clutch cone (8); loosen the
fixing screws (11) of the rope/chain stripper (12) and remove it. Pull
off the gypsy (9).
Clean all the parts removed to avoid corrosion, and grease the shaft
thread (18, 19, 20 or 21) and the gypsy (9) where the clutch cones
rest (7 and 9) (use grease suitable for marine environment).
Remove any oxide deposits from the terminals of the electric motor
and the contactor unit; grease them.
51 Terminal board gasket 1000W PCGPMMR00000
52 Terminal board cover 1000W PCCPPMMR0000
53 Screw MBV02213AXSC
54 Bottom gasket 1000W PGGPMFN00000
55 Bottom protec cover 1000W PCCPPMFN0000
56 Cable outlet PPM20B000000
57
Gearbox 2000W - Quick series
SLMR20TG7000
58 Screw MBV0825MXE00
59 O-ring - gearbox 2000W PGR025980000
60
Watertight motor casing
2000/2300W
PCCCPM200000
61 Key 6x6x30 MBH0606030X0
62 Electric motor 2000W 24V EMF202400000
63 Bottom cover O-ring PGR035250000
64 Bottom cover PCCPPMFN2000
65 Lower terminal board gasket PCGPMMR2N000
66 Upper terminal board gasket PCGPMMR2S000
67 Upper terminal board cover PCCPPMMR2000
68 Self-tapping screw M3.9x22 MBV03922AXCC
69 Self-tapping screw M3.9x32 MBV03932AXCC
70 Gearbox flange gasket Top TG60 PGFLRDTG6000
71 Gearbox flange gasket Top TG70 PGFLRDTG7000
72 O-ring - bush PGR031500000
POS.
DESCRIPTION CODE
1 Bent anchor winch lever
ZSLMSHR10000
2 Chrome-plated “DN” clutch bush SGMSD1500000
3 O-ring PGR033000000
4 Gypsy cover SGMSGB10AL00
5 Screw M5x16 MBV0516MXCE0
6 Drum SPMSE15DNR01
7 Chrome-plated “DN” clutch bush SGMSDCPDN150
8 Upper clutch cone SLMSF15DND00
9A Gypsy 1500W 10mm - 3/8" ZSB151038000
9B Gypsy 1500W 12/13mm ZSB151213000
10 Bottom clutch cone SLMSF15DNN00
11 Screw 6x35 MBV0635MXCE0
12 Chrome-plated rope/chain stripper MSNDN0000000
13 Spring washer MBR307025X00
14 Oil seal 30x55x10 PGPRL3055100
15 Internal circlip MBAN5520Y000
16 External circlip MBAE3015Y000
17 Bearing MBJ600600000
18 Oil seal 30x50x7 PGPRL3050070
19 Short Shaft 1500W MSAS15367R00
20 Short Shaft 1700/2000W MSAS20367R00
21 Long shaft 1500W MSAS15411R01
22 Long shaft 1700/2000W MSAS20411R01
23 Key MBH0807140X0
24 “DH” chain fall cover -
25 Screw -
26 “DH” chain guide support SGMSN15DN000
28 Molla tendicima MMTC15DNC000
27 Mooring rope puller pin -
29 Pressure lever PD LVTD150000
30 Gypsy lock spring MMBLBRATC000
31 Gypsy lock lever MSH10ATCX000
32 Gypsy lock lever control MSVLBBATCX00
33 Lever lock control safety PDSCLVBB0000
34 Gypsy lock pin MSVPR10ATC00
35 DH base -
36 Gasket / jig DYLAN DH -
37 Sensor Reed KNREEDCL0000
38A Stud 8x80 MBP080807X00
38B Stud 10x110 MBP101100X00
39A Washer 1500W MBR08X000000
39B Washer 1700/2000W MBR10X000000
40A Spring washer 1500W MBR08XDE0000
40B Spring washer 1700/2000W MBG10X000000
41A Nut 1500W MBD08MXEN000
41B Nut 1700/2000W MBD10MXEN000
42
Insert for manual anchor weighing
PDRM15000000
43
Gearbox
1500W - Quick series SLMR15TG7000
44 Washer MBR061815X00
45 Self-locking nuts MBD06MXET000
46 O-ring - gearbox 1500/1700W PGR023000000
47 Gearbox 1700W - Quick series
SLMR17TG7000
48 Key 5x5x15 MBH050515F00
49A Electric motor 1500W 12V EMF071200000
49B Electric motor 1700W 12V EMF101200000
49C Electric motor 1700W 24V EMF102400000
50
Motor casing watertight 1500/1700W
PCCCPM100000
