Rath 2500-12RC User Manual

Base Station Mounting
RATH® recommends mounting the Base Station 60” from the oor to the center of the unit.
2500-205D, 2500-210D
Page 9
Y
G
R
B
Y
G
R
B
Y
G
R
B
Y
G
R
B
Y
G
R
B
Y
G
R
B
Y
G
R
B
Y
G
R
B
Y
G
R
B
Y
G
R
B
1
2 3 4 5 6 7 8 9 10
HOOK SWITCH
Y
G
R
B
Y
G
R
B
FRONT PANEL/COVER
LEFT SIDE
BOTTOM SIDE
CONTROL INSIDE
11.60” [294.64]
12.56” [319.09]
0.82” [20.72]
0.69” [17.46]
0.22” [5.71]
1.98” [50.19]
0.69” [17.46]
4.02” [102.07]
0.25” [6.35]
0.13” [3.18]
0.32” [8.05]
1.03” [26.25]
1.27” [32.38]
11.60” [294.64]
12.56” [319.09]
0.33” [8.49]
5.81” [147.48]
ø0.28” [ø7.18]
11.60” [294.64]
0.84” [21.27]
4.34” [110.17]
1.68” [42.67]
ø0.50” [ø12.70]
ø0.88” [ø22.23]
0.45” [11.41]
0.69” [17.50]
