RG27/35/37 Operation • Service • Maintenance
26
Getting to know your machine
Operation
1. Operator Panel
2. Fuel / Hydraulic Tanks
3. Blade
4. Steer Axle
5. Safety Curtains
6. Cutter Wheel
7. Cutter Boom Belt
8. Engine
9.Swing Out Arm
1
2
3
4
5
5
5
6
7
8
911
10
12
