1.UsingtheSurface/Flushmountingtemplateasaguide ,cuttherelevantcutoutholeinthe

mountingsurface,ifyouareFlushmountingtheMFD,alsofollowtherebateinformationonthe

mountingtemplate.

2.Screwthe4xstudsintotherearoftheMFD.

3.RemovethebackingfromthegasketandattachittotherearoftheMFD,ensuringthatthe

black,softsideisagainsttherearoftheMFD.

4.InserttheMFDintothecutouthole.

Important:Inabovedeck s,ﬂushmountinstallations,marinegradesiliconeshouldbeusedtoseal

thegapbetweentheedgeofthemountingsurfaceandtheedgeoftheMFD.

5.PlacetheT runnionadaptoroverthebackoftheMFD.

6.SecuretheMFDinpositionbyhand-tighteningthethumbnutsontothestuds.

Important:T opreventpotentialdamagetotheunit,doNOTovertightenthethumbnuts.Hand

tightenonly.

7 .IfrequiredinsertyourMicroSDcardintotheMFDcardreader,locatedbehindtherubberbungon

therearoftheMFD.

8.Routeandconnectnecessarycables.

Note:Thesuncoverprovidedinthebo xisforuseinTrunnionbracketinstallations,whenSurface

mountingtheproductaccessorysuncoverR70527isrequired.Nosuncoverisavailablefor

Flushmountinstallations.
