2
SECTION 2
INSTALLATION
2.1 UNPACKING AND INSPECTION
Use care when unpacking the unit from the shipping carton to prevent damage to the
contents. It is also good practice to save the carton and the interior packing material. The
original packing material should be used in the unlikely event it is necessary to return the
unit to the factory.
2.2 EQUIPMENT SUPPLIED
The following is a list of materials supplied with the Ray48:
Description Part No.
Ray48 White E43020
Ray48 Charcoal E43021
Handbook 81233
Microphone Bracket for White Radio R49099
Power/External Speaker Cable G623680-3
Mounting Yoke for White Radio R49101
2.2.1 Optional Accessories
Description Part No.
Flush Mount Kit E46034
2.3 PLANNING THE INSTALLATION
When planning the installation for your Ray48, the following conditions should be
considered to insure dependable and trouble-free operation.
• The mounting location should be easily accessible to allow operation of the front panel.
• The radio should be located at least 3 feet from the antenna.
• There should be adequate ventilation for the control unit.
• A sufficient space should be secured behind the transceiver to allow for proper cable
connections to the rear panel connectors.
Microphone Bracket for Charcoal Radio R49100
Mounting Yoke for Charcoal Radio R49102
Yoke Knob w/Spacer for White Radio R49094
Yoke Knob w/Spacer for Charcoal Radio R49096
