2
Need Help? Visit our web site for replacement parts and product support at www.razor.com or call toll-free at
866-467-2967 Monday - Friday 8:00 AM - 5:00 PM Pacific Time. Please have the product I.D. code (located on the
bottom of the frame) available for better assistance.
BEFORE YOU BEGIN
Remove contents from box. Remove the separators that protect the components from damage during shipping. Inspect
the contents of the box for scratches in the paint, dents or kinked cables that may have occurred during shipping.
Because the scooter was 95 percent assembled and packed at the factory, there should not be any problems, even if the
box has a few scars or dents.
MAKE SURE POWER SWITCH IS TURNED “OFF” BEFORE CONDUCTING ANY ASSEMBLY OR
MAINTENANCE PROCEDURES.
Estimated Assembly and Set-Up Time
Razor recommends assembly by an adult.
Allow up to 10 minutes for assembly, not including initial charge time.
Allow up to 12 hours for charge (see page 5 for charging information).
WARNING:
DO NOT USE NON-RAZOR
PRODUCTS WITH YOUR RAZOR
ELECTRIC SCOOTER. The
scooter has been built to certain
Razor design specifications. The
original equipment supplied at
the time of sale was selected
on the basis of its compatibility
with the frame, fork and all
other parts. Certain aftermarket
products may not be compatible
and will void the warranty.
Required Tools
5 mm Allen wrench
(Included)
Two (2) 4 mm Allen Wrenches
(E200s only)
Brake Lever
Handlebar Stem
Twist Grip Throttle
Valve Extender
(Inside Grip)
On/Off Switch
Charger Port
Reset Button
- Battery
- Control Module
Limiter
Collar Clamp
Front Fork
Charger
(Note: Charger design may vary
from one shown)
Motor
Product ID Locations:
See locations to the left
1. Handlebar Stem
2. Underneath battery tray
3. Charger
4. UPC side of box (not shown)
1.
2.
3.
Phillips Screwdriver
(E200s only)
Valve Extender
(Located in right
handlebar grip)
To Next Page
