Side Panel Connections
Connecting a computer
To connect a computer, follow these steps:
1. Connect the VGA port on the side of TV to the VGA output jack o
f device via D-sub 15-pin cable.
2. Connect the PC Audio In jack on the side of TV to the audio out
put jack of computer with audio cable (3.5mm).
PC Connection
The picture below is an example of a connection using your TV as a PC monitor.
How to Obtain Various Kinds of Input Sources
After connection is done, press INPUT button on remote control or TV top panel to choose the input source you need.
See page 21, Basic Operation of TV.
Note: If you want to use your TV as a monitor, please notice that the maximum resolution for 19LA30RQ is 1366*768.
Please set the computer graphic correctly.
15
The back of TV
Speaker or
headphone
VGA
PC
To Next Page
