The panel can be scratched easily, so please:
1. Choose an absolutely flat surface to place the TV on.
2. Use soft cloth or cushion to face the TV panel.
Do not put TV on the table directly.
Always unplug the AC cord first when installing/removing
the stand.
Step One
Place the TV faced down on a soft cloth or cushion to prevent the
panel from being damaged.
TV LED32B30RQD is packaged with the TV stand separated from the cabinet. To setup the TV table stand, please carry out
the installation according to the instructions below.
TV Stand Installation
9
Step Three
Take the base. Please align four holes of the base and four
screwholes of the neck, insert the base to the neck, and then
insert the 4 screws and tighten them.
RS01PWA414HT
Pedestal Screws Quantity Part #
4pcsM4 x 14mm
Please take note of the base direction:
Step Two
Take the neck. Please align the screw holes of the neck and the
TV, and then insert the 4 screws into the 4 holes on the neck and
tighten them.
RS01TB416H
Pedestal Screws Quantity Part #
4pcsM4 x 16mm
Longer side
Longer side
The bottom view of the TV (Front cabinet faces down)
To Next Page
