TV LED42A45RQ is packaged with the base of TV stand separated from the cabinet. To setup the base of TV table stand, please

carry out the installation according to the instructions below.

Step One

Place the TV faced down on a soft cloth or cushion to prevent the LED LCD panel from being damaged.

Note:

1. The LED LCD panel can be scratched easily, so please choose an absolutely ﬂat surface to place the TV, and use soft cloth or

cushion to protect the TV panel. Do not put TV on table directly.

2. Always unplug the AC cord ﬁrst when installing or removing the stand.

Step Three

Please align the six holes of the base and six screwholes of the neck (align the location labels on the back of base and neck),

then insert the base to the neck.

Step Four

Then insert PWA4*12 screws (all same in size) and tighten them.

Please refer to the picture given below:

The bottom view of the TV ( Front cabinet faces down)

Note:

1. Be sure to follow the instructions. Incorrect installation of the stand may result in the TV falling over.

2. Make sure to distinguish between the front and back of the Stand base.

3. Make sure that at least two persons lift and move the TV.

Do not insert your fingers into the stand base slot of the TV when installing the stand base.

Step Two

Take the base of stand. You should take notice of direction about base installation,

please refer to the picture given right side:

TV Front cabinet

Back cabinet

TV Stand Installation

RS01PWA412H

Pedestal Screws Quantity Part #

6pcsPWA4 x 12mm
