6
Introduction
2. Rear View
2). Headphone out
: Connect it to your headphone or audio equipments.
5).
4).
RF
: Connect antenna or cable 75 Ohm coaxial to receive TV signal.
7).
COAX : Digital audio output.
10).
YPbPr : Connect them to the component video output of video device.
: Connect it to the HDMI output of video device.
6).
HDMI1/2/3
L/R in
: Connect them to audio output of video device (shared with YPbPr).
11).
L/R out
: Connect them to audio equipments.
VIDEO : Connect it to video output of video device.
9).
8). Service
: For service use only.
AC POWER IN:
Connect to an earth 100-240V~ 50/60Hz outlet with the power cable.
1).
3).
RF VGA HDMI1
HDMI2
HDMI3
SERVICE
VIDEO
YPbPr
HEADPHONE OUT
PC IN
COAX
RF VGA HDMI1
HEADPHONE OUT
PC IN
R
L
R
L
Audio out
Audio in
