Rheem 14AJM SERIES User Manual

Air
Electrical and Physical Data
14AJM Series
36
Model
Number
14AJM
ELECTRICAL PHYSICAL
Phase
Frequency (Hz)
Voltage (Volts)
Compressor
Fan Motor
Full Load
Amperes
(FLA)
Minimum
Circuit
Ampacity
Amperes
Fuse or HACR
Circuit Breaker
Outdoor Coil
Refrig.
Per
Circuit
Oz. [g]
Weight
Rated Load
Amperes
(RLA)
Locked Rotor
Amperes
(LRA)
Minimum
Amperes
Maximum
Amperes
Face Area
Sq. Ft. [m
2
]
No.
Rows
CFM [L/s]
Net
Lbs. [kg]
Shipping
Lbs. [kg]
Rev. 6/14/2012
18 1-60-208/230 9/9 48 0.8 12/12 15/15 20/20 16.39 [1.52] 1 2805[1324] 112 [3175] 154 [69.9] 171 [69.9]
24 1-60-208/230 13.5/13.5 58.3 0.8 18/18 25/25 30/30 16.39 [1.52] 1 2805[1324] 105.6 [2994] 154 [69.9] 171 [69.9]
30 1-60-208/230 12.8/12.8 64 1.4 18/18 25/25 30/30 16.39 [1.52] 1 2915[1376] 112 [3175] 157 [71.2] 175 [71.2]
36 1-60-208/230 16.7/16.7 79 1.9 23/23 30/30 35/35 21.85 [2.03] 1 3435[1621] 130.4 [3697] 181 [82.1] 201 [82.1]
42 1-60-208/230 17.9/17.9 112 2.8 26/26 30/30 40/40 21.85 [2.03] 1 3550[1675] 145.12 [4114] 205 [93] 225 [93]
48 1-60-208/230 21.8/21.8 117 2.8 31/31 40/40 50/50 21.85 [2.03] 2 4310[2034] 216 [6124] 249 [112.9] 269 [112.9]
49 1-60-208/230 19.9/19.9 109 1.9 27/27 35/35 45/45 21.85 [2.03] 2 3615[1706] 213 [6039] 249 [112.9] 269 [112.9]
56 1-60-208/230 21.4/21.4 135 1.9 29/29 35/35 50/50 21.85 [2.03] 2 3615[1706] 241 [6832] 254 [115.2] 274 [115.2]
60 1-60-208/230 26.4/26.4 134 2.8 36/36 45/45 60/60 21.85 [2.03] 2 4310[2034] 240 [6804] 254 [115.2] 274 [115.2]
NOTE: Factory Refrigerant Charge includes refrigerant for 15 feet of standard line set.
[ ] Designates Metric Conversions
Electrical and Physical Data

Rheem 14AJM SERIES Specifications

General

Brand	Rheem
Model	14AJM SERIES
Category	Air Conditioner
Language	English
