Overview of the functionality provided by each button of
the user interface.
MENU: To enter user menu mode for access to Tempera-
tures, Heater Status, and Heater Information.
UP/DN: To navigate through heater menus for adjustment
of settings.
OK: To confirm storage of adjustments to system settings.
HELP: Access to heater information in the event of a
system fault.
DISPLAY WINDOW: Provides information as changes
are made to control.
User Interface
MENU: To enter user
menu mode for access
to Temperatures, Heater
Status, and Heater Infor-
mation.
HELP: Access to
heater information in the
event of a system fault.
OK: To confirm storage
of adjustments to system
settings.
UP/DN: To navigate
through heater menus for
adjustment
of settings..
DISPLAY WINDOW:
Provides information
as changes are made
to control.
Figure 11 - User Interface
