Rheem PH-16(FISN)(FISP) User Manual

23
Installing the water heater:
Typical Installation of Water Heater
(Venting Required for Indoor Models Only)
Discharge
Line
(To Suitable Drain)
To Hot Water
Faucet(s)
Relief
Va l v e
Union
Drain Valve
6" (15 cm) Air Gap
Manual Gas
Appliance
Shut-off
(supplied)
Sediment
Tra p
Manual
Gas Supply Line
Shut-off
Va l v e
Union
Cap
Cold Water
Supply
Shut-off
Va l v e
Check
Va l v e
1/4" Per Foot Downward Pitch
90û Elbow
Vent Adapter
Power
Supply
Cord
Water Filter
Drain Valve
Drain
Hose
(To Suitable Drain)
NOTICE: The National Fuel Gas Code (NFGC) and B149 mandates a manual gas shut-off valve: See
NFGC/B149 for complete instructions. Local codes or plumbing authority requirements may vary from
the instructions or diagrams provided and take precedent over these instructions.
Vacuum Relief Valve
(Not Supplied)
If required, install per local codes
and valve manufacturer’s
instructions.
Water Inlet
Water
Outlet
Drain
Pressure Relief
Valve
Hot Water Service
Valve
Cold Water
Service Valve
Alternate Water Piping Arrangement
with Optional Valve Kit
Discharge
Line
(To Suitable Drain)
To Hot Water
Faucet(s)
Relief
Va l v e
Union
Drain Valve
6" (15 cm) Air Gap
Manual Gas
Appliance
Shut-off
(supplied)
Sediment
Tra p
Manual
Gas Supply Line
Shut-off
Va l v e
Union
Cap
Cold Water
Supply
Shut-off
Va l v e
Check
Va l v e
Water Filter
Drain Valve
Drain
Hose
(To Suitable Drain)
On/Off
Switch
∞F
PRIORITY
POWER
ON/OFF
Remote
Control
Indoor Models
Outdoor Models
Install indoors only.
