GENERAL DATA—RRKA- SERIES
Model RRKA- Series A036CK04E A036CK06E A036CK08E A036CK10E
Cooling Performance
1
Gross Cooling Capacity Btu [kW] 37,400 [11] 37,400 [11] 37,400 [11] 37,400 [11]
EER/SEER
2
9/10 9/10 9/10 9/10
Nominal CFM/ARI Rated CFM [L/s] 1200/1200 [566/566] 1200/1200 [566/566] 1200/1200 [566/566] 1200/1200 [566/566]
ARI Net Cooling Capacity Btu [kW] 36,000 [10.5] 36,000 [10.5] 36,000 [10.5] 36,000 [10.5]
Net Sensible Capacity Btu [kW] 24,723 [7.2] 24,723 [7.2] 24,723 [7.2] 24,723 [7.2]
Net System Power kW 4 4 4 4
Heating Performance (Package Gas/Electric)
3
Heating Input Btu [kW] 40,000 [11.7] 60,000 [17.6] 80,000 [23.4] 100,000 [29.3]
Heating Output Btu [kW] 32,400 [9.5] 48,600 [14.2] 64,800 [19] 81,000 [23.7]
Temperature Rise Range ˚F [˚C] 20-50 [11.1/27.8] 30-60 [16.7/33.3] 40-70 [22.2/38.9] 45-85 [25/47.2]
Net Weight lbs. [kg] 412 [187] 417 [189] 422 [191] 426 [193]
Steady State Efficiency (%) 78.1 78.1 78.3 77.6
No. Burners 2 3 4 5
No. Stages 1 1 1 1
Gas Connection Pipe Size in. [mm] 0.5 [12.7] 0.5 [12.7] 0.5 [12.7] 0.5 [12.7]
Compressor
No./Type 1/Copeland Scroll 1/Copeland Scroll 1/Copeland Scroll 1/Copeland Scroll
Outdoor Sound Rating (dB)
5
76 76 76 76
Outdoor Coil—Fin Type Louvered Louvered Louvered Louvered
Tube Type Smooth Smooth Smooth Smooth
Tube Size in. [mm] OD 0.375 [9.5] 0.375 [9.5] 0.375 [9.5] 0.375 [9.5]
Face Area sq. ft. [sq. m] 10.5 [0.98] 10.5 [0.98] 10.5 [0.98] 10.5 [0.98]
Rows / FPI [FPcm] 1 / 18 [7] 1 / 18 [7] 1 / 18 [7] 1 / 18 [7]
Net Latent Capacity Btu [kW] 11,277 [3.3] 11,277 [3.3] 11,277 [3.3] 11,277 [3.3]
Indoor Coil—Fin Type Louvered Louvered Louvered Louvered
Tube Type Rifled Rifled Rifled Rifled
Tube Size in. [mm] 0.3125 [7.9] 0.3125 [7.9] 0.3125 [7.9] 0.3125 [7.9]
Face Area sq. ft. [sq. m] 7.6 [0.71] 7.6 [0.71] 7.6 [0.71] 7.6 [0.71]
Rows / FPI [FPcm] 1 / 18 [7] 1 / 18 [7] 1 / 18 [7] 1 / 18 [7]
Refrigerant Control Capillary Tubes Capillary Tubes Capillary Tubes Capillary Tubes
Drain Connection No./Size in. [mm] 1/.75 [19.05] 1/.75 [19.05] 1/.75 [19.05] 1/.75 [19.05]
Outdoor Fan—Type Propeller Propeller Propeller Propeller
No. Used/Diameter in. [mm] 1/20 [508] 1/20 [508] 1/20 [508] 1/20 [508]
Drive Type/No. Speeds Direct/1 Direct/1 Direct/1 Direct/1
CFM [L/s] 2730 [1288] 2730 [1288] 2730 [1288] 2730 [1288]
No. Motors/HP 1 at 1/5 HP 1 at 1/5 HP 1 at 1/5 HP 1 at 1/5 HP
Motor RPM 1075 1075 1075 1075
Indoor Fan—Type FC Centrifugal FC Centrifugal FC Centrifugal FC Centrifugal
No. Used/Diameter in. [mm] 1/10x9 [254x228.6] 1/10x9 [254x228.6] 1/10x9 [254x228.6] 1/10x9 [254x228.6]
Drive Type/No. Speeds Direct/3 Direct/3 Direct/3 Direct/3
No. Motors 1 1 1 1
Motor HP 1/2 1/2 1/2 1/2
Motor RPM 1725 1725 1725 1725
Motor Frame Size 48 48 48 48
Filter—Type Field Supplied Field Supplied Field Supplied Field Supplied
Furnished No No No No
(No.) Size Recommended in. [mm] (1)1x24x24 [25x610x610] (1)1x24x24 [25x610x610] (1)1x24x24 [25x610x610] (1)1x24x24 [25x610x610]
Refrigerant Charge Oz. [g] 62 [1758] 62 [1758] 62 [1758] 62 [1758]
Weights
Ship Weight lbs. [kg] 452 [205] 457 [207] 462 [210] 466 [211]
AFUE (%)
4
80 80 80 80
California Seasonal Efficiency (%) 75.1 76.3 77 77.3
CONTINUED
NOMINAL SIZES 3-5 TONS [10.6-17.6 kW]
See Page 10 for Notes. [ ] Designates Metric Conversions
