34
V
enting for Dir
ect-V
ent W
ater Heater
Standard V
ertical Vent T
ermination
CAUTION:
The condensate collector must
be used with vertical vent
installation.
Support Hanger
Fire Stop
Fire Stop
Adjustable
Roof
Flashing
Storm
Collar
Air
Intake
V
ertical
T
ermination
Adapter
Support Clamp
3" to 5" Concentric Pipe
Condensate
T
rap
T
o Drain:
Dispose of
condensate in
accordance to
local codes
1/4" Per Foot Upward Slope
INST
ALLA
TION INSTRUCTIONS
V
enting
33
35
