Replacement Parts.
18
Key No. Description
1 Dip Tube
2 Grommet, Large
Grommet, Small
3 Seal Ring, Large
Seal Ring, Small
4 Vacuum Valve Assembly
5 Temperature and Pressure Relief Valve
6 Nipple, 3/4" NPT x 3"
7 Reducer Bushing, 3/4" NPT x 1" NPT
8 Knock-Out Bracket
9 Screw, #8 x 3/4"
10 Junction Box Cover
11 Screw #8-16 x 5/8"
12 Upper Thermostat
13 Upper Protector
14 Screw, #10-16 x 5/8"
15 Thermostat Cavity Insulation
16 Upper Access Panel
17 Screw, #10-16 x 5/8"
18 Access Panel Cover Insulation
19 Access Panel Cover
20 Element Gasket
21 Upper Heating Element (Includes Key No. 20)
22 Lower Thermostat
23 Lower Protector
24 Lower Access Panel
25 Lower Heating Element (Includes Key No. 20)
26 Drain Valve
27 5/16-18 Cap Screw
28 Lock Washer
▲
Element Wrench
▲
Pipe Wrap Energy Kit
▲
Use and Care Manual
▲ Not Illustrated
