Ricoh Caplio R1 User Manual

105
Changing Camera Settings
Note
• When the Power-Save mode is set to ON, if the power is turned on or the mode dial is
turned to another position, a warning appears for about two seconds to indicate Power-
Save mode.
• Pressing the F (Flash) button allows you to turn the LCD Monitor Display on, and then
change the flash setting (see P.33). Press the shutter button or O button to turn the LCD
Monitor Display off.
Caution
If you have activated Power-Save mode, power consumption will be reduced, but there are
the following limitations:
• Processing time may be slower.
• It works only in Still Image/Movie modes. It does not work in Playback Mode.

Ricoh Caplio R1 Specifications

General

Megapixel	4 MP
Camera type	Compact camera
Sensor type	CCD
Maximum image resolution	2560 x 1920 pixels
Still image resolution(s)	640 x 480, 1280 x 960, 1600 x 1200, 2304 x 1728
Optical zoom	- x
Focal length range	4.6 - 22.2 mm
Lens structure (elements/groups)	9/7
Interface	USB 1.1, AV out
Digital SLR	No
Built-in flash	Yes
Camera shutter speed	1 - 1/2000 s
Focal length (35mm film equivalent)	28 - 135 mm
Normal focusing range	0.3 - ∞ m
Macro focusing range (tele)	0.13 - ∞ m
Macro focusing range (wide)	0.01 - ∞ m
ISO sensitivity	Auto
Video formats supported	AVI
Maximum video resolution	320 x 240 pixels
Display diagonal	1.8 \
Display resolution (numeric)	110000 pixels
Scene modes	Documents, Night, Portrait, Landscape (scenery)
White balance	daylight, Fluorescent, Tungsten
Self-timer delay	2, 10 s
Product color	Black
Battery type	DB-50
Battery life (CIPA standard)	500 shots
Number of batteries supported	1
Flash modes	auto, manual, Red-eye reduction
Compatible memory cards	mmc, sd

Weight and Dimensions

Depth	25 mm
Width	100.2 mm
Height	55 mm
Weight	150 g
