Revision Lists
Version Section Details
1.00 -
Initial release of this document
Created this manual for D146 series.
1.10
All
Revised all sections according to the release
of D197 series
Modified some parts name.
Added the following sections:
> ADF Covers
> Document Feed Components
> Electrical Components
> Original Feed Drive
Read This First > Safety and Symbols Modified some icons.
Replacement and Adjustment > ADF
Removal
Modified Step 1 through Step 6.
Replacement and Adjustment >
Platen Adjustment
Changed the name for fastener in Step 3.
Replacement and Adjustment > ADF
Covers > ADF Rear Cover
Modified items need to be removed in Step
3.
Replacement and Adjustment >
Document Feed Components >
Original Feed Unit
Modified Step 3.
Replacement and Adjustment >
Document Feed Components > Pick-
up Roller / Transport Belt
Added a Note for Step 2.
Replacement and Adjustment >
Document Feed Components >
White Roller
Added this section.
Replacement and Adjustment >
Electrical Components > CIS Unit
Modified the procedure.
